Electric Powerful Linear actuator With 24Vdc FOR Scissor Lifting
Table
| Type | Electric linear actuator |
| Motor type | Brush DC motor |
| Cable | Bare wire 0.4m |
| Voltage | 24VDC |
| Screw type | ACME |
| Noise level | ≤75dB |
| Limit switches | Integrated non adjustable |
| Stroke tolerance | ±3mm |
| Duty cycle | 25% |
| Production class | IP66 |
| Feedback | Hall sensor/pot |
| Operating and storage temperature | -40℃~+65℃ |
| Manufacturing quality standards | ISO9001:2015 |
| CE Label | Yes |
Load & speed & current of linear actuator
| Product mode | Max load(N) | Speed (mm/s) |
| Industrial linear actuator | 12000 | 6.5 |
| 10000 | 13 | |
| 7000 | 17 | |
| 6500 | 20 | |
| 5000 | 25 | |
| 3200 | 38 |
LINEAR ACTUATOR STROKE DATA
| Stroke length (mm) | 50 | 100 | 150 | 200 | 250 | 300 | 400 |
| Retracted length(mm) | 310 | 300 | 350 | 400 | 450 | 550 | 650 |
| Extended length (mm) | 360 | 400 | 500 | 600 | 700 | 850 | 1050 |
More linear actuators for you choose:
| Model | Picture | Application | |
|  | Sweeper car | |
| Lawn mover | |||
| Voltage:12V/24V/36V/48V | Snow plough | ||
| Max load 1200N | Dog treadmill | ||
| Max speed:100mm/s | LED Car | ||
| Duty cycle:25% | Arrow board trail | ||
| Limit switch: Inner | Forklift | ||
| IP grade: IP65 | braking system | ||
| Others… | ||
| Heavy-duty linear actuator |  | ||
| Voltage:12V/24V/36V | Forklift | ||
| Max load 7000N | AGV | ||
| Max speed:35mm/s | Sweeper car | ||
| Duty cycle:25% | Lawn mover | ||
| Limit switch: Inner | Harvesting machine | ||
| IP grade: IP65 | Robotic vehicles | ||
| Noise level:70db-75db | Solar tracker | ||
| Construction machine | |||
| Others… | |||
| Solar tracker linear actuator |  | ||
| Voltage:24V | Solar tracker | ||
| |||
| Max speed:3.3mm/s | |||
| Duty cycle:10% | |||
| Limit switch:Inner | |||
| |||
| Micro linear actuator |  | ||
| Voltage:12V/24V/36V/48V | Application: | ||
| Max load 2000N | Sweeper car, | ||
| Max speed:15mm/s | Lawn mover, | ||
| Duty cycle:25% | Forklift, | ||
| Limit switch:Inner | Dog treadmill, | ||
| IP grade:IP66 | Furniture, | ||
| Noise level:45db | Others... |
